Backups Overview#

This page relates only to the ABF production version of Cobalt.

Basic Backups#

We use AWS Relational Database Service (RDS) for our databases. This is a fully managed service and handles the basic housekeeping that we need to perform. Full backups (RDS calls them snapshots) are taken each day at about 2:30am. They are retained for 14 days in production and 7 days for the other environments.

Snapshots can be taken manually, and it recommended that this happens for any major release.

Taking a snapshot prevents database updates at that time and can take time if the database is large.

Basic Restores#

You can restore a snapshot from the RDS management console. It will be given a new name and you will need to point the associated Django Elastic Beanstalk environment at the new database in order to use it.

Additional Off System Backups#

While it is unlikely that anything will go wrong with RDS itself, it is possible for other factors to affect our database. For example, failure to pay the bill would result in the account being shutdown or human error could cause the production database and all of its snapshots to be deleted when the intention was to remove UAT.

For this reason we have an off-system backup which runs daily. This is not without risk as it needs to access production data and systems in order to copy the data. It also requires maintenance and testing. The IT equivalent of the medical joke “The operation was successful, but the patient died” is “The backups worked perfectly, it was the restores that had problems.” For that reason, as well as copying the data we also restore and test it each time.

As of 2025, the backup process takes a couple of hours. During that time many things could happen as the database is not locked to prevent updates. For example, we could backup the payments tables, recording a balance for a user of $75. Then before we backup the events tables, they enter an event and their balance is now $20. If we restore from this backup, they will have been given free entry to the event because we will restore their balance to $75 but also keep the entry. It is actually a lot worse than this as we can have integrity issues with foreign keys.

In order to address this, we don’t backup from the live database. Instead we use a snapshot taken by RDS every day, and build a new temporary database server that has no users, and we create the backup from that.

How It Works#

The code lives in utils/aws/off_system_backups. It can run pretty much anywhere, but needs a copy of the cobalt code. It needs to run after the RDS snapshot has been taken.

Setting Up on Lightsail#

Here are the steps to set up the off system backups on AWS Lightsail. Lightsail is an easy way to set up an EC2 instance that you can access remotely.

Lightsail Instance#

  1. Go to the AWS Lightsail Console

  2. Create a new instance. Choose Linux -> OS Only -> Amazon Linux 2023.

  3. Choose Dual Stack.

  4. 2GB is probably enough.

  5. Give it a name and create it.

Connect Over SSH#

The Lightsail web based client is pretty awful, you are better connecting over ssh so you can cut and paste easily.

Go to your instance and into the Connect tab. Download the default key and move it to .ssh with a better name. Note the IP address.

Now you should be able to connect, e.g.:

ssh -i ~/.ssh/cobalt-lightsail.pem ec2-user@3.106.143.77

The authenticity of host '3.106.143.77 (3.106.143.77)' can't be established.
ED25519 key fingerprint is SHA256:nsJIr9yMR2rproGtbH0OsmqeTkGer69KNs+/QRZFaWk.
This key is not known by any other names.
Are you sure you want to continue connecting (yes/no/[fingerprint])? yes
Warning: Permanently added '3.106.143.77' (ED25519) to the list of known hosts.
   ,     #_
   ~\_  ####_        Amazon Linux 2023
  ~~  \_#####\
  ~~     \###|
  ~~       \#/ ___   https://aws.amazon.com/linux/amazon-linux-2023
   ~~       V~' '->
    ~~~         /
      ~~._.   _/
         _/ _/
       _/m/'
Last login: Fri Jun 20 07:20:34 2025 from 54.240.194.193
[ec2-user@ip-172-26-11-153 ~]$

Install Postgres#

Install the version of Postgres that you want. For example:

sudo yum install postgresql17-server.x86_64

You can find the different versions:

sudo yum list | grep postgr

Configure Postgres#

Initialise Postgres by running:

sudo postgresql-setup initdb --unit postgresql
 * Initializing database in '/var/lib/pgsql/data'
 * Initialized, logs are in /var/lib/pgsql/initdb_postgresql.log

Now start it:

sudo systemctl start postgresql

If there are problems have a look at what the issue was:

systemctl status postgresql

Once it is working, get it to start automatically:

sudo systemctl enable postgresql

Check you can connect to Postgres:

sudo -u postgres psql
psql (17.5)
Type "help" for help.

postgres=#

While you are working with Postgres, lets add a couple of other things:

# Nasty legacy from some consultants
sudo yum install postgresql17-contrib

sudo -u postgres psql
psql (17.5)
Type "help" for help.

postgres=# create extension pg_trgm;

# change authentication method for Postgres
vi /var/lib/pgsql/data/pg_hba.conf

# TYPE  DATABASE        USER            ADDRESS                 METHOD

# "local" is for Unix domain socket connections only
local   all             all                                     trust
# IPv4 local connections:
host    all             all             127.0.0.1/32            trust
# IPv6 local connections:
host    all             all             ::1/128                 trust

sudo -u postgres psql
create user cobalt with encrypted password 'F1shcake';

sudo -u postgres createuser -s ec2-user
sudo -u postgres createdb ec2-user

sudo -u postgres psql
    psql (17.5)
    Type "help" for help.

    postgres=# ALTER USER "ec2-user" WITH SUPERUSER;
    postgres=# create user cobalt with encrypted password 'F1shcake';
    postgres=# create database cobalt with owner cobalt;

Install Python#

At the time of writing, we were using Python 3.13, but only 3.12 was easily available on Lightsail. It is unlikely to make much difference for the off system backups.

To see the available versions of python, run:

sudo yum list | grep python

To install Python 3.12, run:

sudo yum install python3.12.x86_64

You may need to find where Python has been installed. You can find this by using RPM. e.g. for the version we just installed:

rpm -ql python3.12.x86_64

/usr/bin/pydoc3.12
/usr/bin/python3.12
/usr/lib/.build-id
/usr/lib/.build-id/69
/usr/lib/.build-id/69/6ecd3c99623b75e63f0fd494e0edf164ba485b
/usr/share/doc/python3.12
/usr/share/doc/python3.12/README.rst
/usr/share/man/man1/python3.12.1.gz

So we want to use /usr/bin/python3.12.

Install Git#

Git isn’t installed by default so run:

sudo yum install git

Directory and Git#

Standard set up for Cobalt:

# Create a directory and use it
mkdir c2; cd c2

# Use the python from above to build a virtual environment.
# This will need to upgraded when we upgrade Python
/usr/bin/python3.12 -m venv myenv

# activate it - we need it in the next step
. ./myenv/bin/activate

mkdir cobalt; cd cobalt

# Open Source so we don't need git credentials to get the code
git init
git remote add origin https://github.com/abftech/cobalt.git
git config pull.rebase false

# Use develop as our reference branch
git checkout -b develop
git pull origin develop

SSH Key#

Rsync needs the ssh key for Cobalt. Copy this from your environment into Lightsail, e.g.:

scp -i ~/.ssh/cobalt-lightsail.pem ~/.ssh/cobalt.pem ec2-user@3.106.143.77:/home/ec2-user/.ssh/cobalt.pem

Then log back into the Lightsail instance and change the permissions:

chmod 600 ~/.ssh/cobalt.pem

AWS and EB CLI#

We need both AWS CLIs, the AWS CLI is already installed, but to install the EB CLI run:

pip3 install awsebcli

You will need credentials for this environment. Go to the AWS console and into IAM and create a set of credentials for the user off-system-backups. If old credentials exist, delete them.

Create credentials for CLI use.

Add these to the bottom of ~/.bashrc:

export AWS_ACCESS_KEY_ID=*************
export AWS_SECRET_ACCESS_KEY=****************
Also add::

export AWS_REGION_NAME=ap-southeast-2

You will need some other environment variables:

export AWS_SES_CONFIGURATION_SET=cobalt-test
export AWS_SES_REGION_ENDPOINT=email.ap-southeast-2.amazonaws.com
export RDS_DB_NAME=cobalt
export RDS_HOSTNAME=127.0.0.1
export RDS_PORT=5432
export RDS_USERNAME=cobalt
export RDS_PASSWORD=F1shcake

You can also add activation of the virtual environment and changing into the directory.:

cd c2
source ./myenv/bin/activate
cd cobalt

Exit the session and login again to re-run .bashrc.

Now run:

eb init

Activation File#

This one is a bit lazy, but it makes the off system backup structure match this author’s development environment.

Run:

cd # make sure you are in the home directory
mkdir bin; cd bin
cat << EOF > cobalt.sh
#!/usr/bin/env bash
source ~/.bashrc
EOF
chmod 755 cobalt.sh

Add Disk#

Lightsail doesn’t come with much disk space so we need to add some more.

From the Lightsail console select your instance go to Storage add some storage (256GB should be okay). Connect this to your instance.

Now ssh into the machine and become root (sudo -s).

Show the disks:

# lsblk
NAME          MAJ:MIN RM  SIZE RO TYPE MOUNTPOINTS
nvme0n1       259:0    0   60G  0 disk
├─nvme0n1p1   259:1    0   60G  0 part /
├─nvme0n1p127 259:2    0    1M  0 part
└─nvme0n1p128 259:3    0   10M  0 part /boot/efi
nvme1n1       259:4    0  256G  0 disk

Our new disk is the bottom one (256GB).

It is an unformatted data disk:

# file -s /dev/nvme1n1
/dev/nvme1n1: data

Format it:

# mkfs -t xfs /dev/nvme1n1
meta-data=/dev/nvme1n1           isize=512    agcount=16, agsize=4194304 blks
         =                       sectsz=512   attr=2, projid32bit=1
         =                       crc=1        finobt=1, sparse=1, rmapbt=0
         =                       reflink=1    bigtime=1 inobtcount=1
data     =                       bsize=4096   blocks=67108864, imaxpct=25
         =                       sunit=1      swidth=1 blks
naming   =version 2              bsize=4096   ascii-ci=0, ftype=1
log      =internal log           bsize=4096   blocks=32768, version=2
         =                       sectsz=512   sunit=1 blks, lazy-count=1
realtime =none                   extsz=4096   blocks=0, rtextents=0

Create mount point:

cd /home/ec2-user
mkdir abf_backup
chmod 777 abf_backup
chown ec2-user abf_backup
chgrp ec2-user abf_backup

Mount it and ensure it is mounted every time:

mount /dev/nvme1n1 abf_backup/
vi /etc/fstab

# Add to end (previous lines look different, don't worry):
/dev/nvme1n1 /home/ec2-user/abf_backup/ xfs defaults,nofail 0 2

Reboot your instance and check the file system gets mounted.

Install Other Packages#

Run:

sudo yum install fdupes -y

Setup Cron#

Cron isn’t installed by default, you need to run:

sudo yum install cronie cronie-anacron

sudo systemctl enable crond.service
sudo systemctl start crond.service

Check it is working:

sudo systemctl status crond.service

Now you can add the entry to cron. You need to check when the RDS snapshot is taken and add a little time on to that. Currently (2025), the entry is:

crontab -e
30 16 * * * <path to cobalt>/utils/aws/off_system_backups/off_system_backup_cron.sh

S3 and BackBlaze Setup#

Login to BackBlaze (https://www.backblaze.com/) and create a new application key.

BackBlaze impersonates the AWS APIs so we use AWS commands to set it up.

Set up the profile:

aws configure --profile backblaze

Put in the BackBlaze keyID for AWS Access Key ID, and the BackBlaze applicationKey for AWS Secret Access Key.:

AWS Access Key ID [None]: ***************
AWS Secret Access Key [None]: **********************
Default region name [None]:
Default output format [None]:

After this edit ~/.aws/config to add the region and endpoint_url:

[default]
[profile backblaze]
    region = us-east-005
    endpoint_url = https://s3.us-east-005.backblazeb2.com

Off System Restores#

TBA
