How To Use The Reference Documents

Payments Application

Note

This page has the documentation on how to use this application (externally provided APIs etc). If you are looking for information on how it works internally, you can find that in Supporting the Payments Application.

Module Purpose

Payments handles anything related to money within Cobalt. It is used by the other modules to facilitate and track payments and as such is primarily an internal service function, however it also has some interaction directly with users to view statements and manage auto tops as well as member-to-member transfers.

Payments is tightly couple with Stripe. This was a deliberate design decision as supporting multiple payment engines is an administrative nightmare for payment staff so it is assumed that only one payment gateway will every be used. If a second is required then the code will need to be refactored to include this abstraction.

APIs

User Actions

This section has functions related to user payments.

Get a User’s Balance

get_balance()

from payments.payments_views.core import get_balance

>>> get_balance(user)
100.0

Get a User’s Balance and Last Top Up Date

get_balance_detail()

from payments.payments_views.core import get_balance_detail

>>> get_balance_detail(user)
{'balance': Decimal('100.00'),
 'balance_num': Decimal('100.00'),
 'last_top_up': datetime.datetime(2022, 4, 9, 11, 34, 5, 781492, tzinfo=<UTC>)}

Update a User’s Account

update_account()

You cannot directly change a user’s balance except by applying a transaction to their account. Transactions should have either Stripe, a user or an organisation as the counterparty.

from payments.payments_views.core import update_account

>>> update_account(member=user, amount=50.45, description="Birthday Present", other_member=me)

Attempt A Payment for a Logged in User

payment_api_interactive()

When you have a user trying to do something that involves a payment, you can call payment_api_interactive to make the payment attempt. If the user has sufficient funds then the payment will be processed and you can optionally receive a callback (for success or failure). If the user doesn’t have sufficient funds but is set up for auto top up, then that will be attempted next. Finally, if auto top up is not setup or fails, the user will be taken to the manual top up screen to make a credit card payment.

Note: callbacks are currently hardcoded. to add a new callback you need to update payments.payments_views.core.callback_router().

from payments.payments_views.payments_api import payment_api_interactive

def my_view(request):

return payment_api_interactive(
    request=request,
    member=request.user,
    description="Congress Entry",
    amount=50.25,
    route_code="EVT",
    route_payload="My identifier",
    next_url=reverse("events:enter_event_success"),
    payment_type="Entry to an event",
    book_internals=False,
)

Request, member, description and amount are fairly obvious. payment_type needs to be a valid type of payment. In a future release this will be changed to an enum.

Whenever you use payment_api_interactive there will be a user on the end of this who needs to be interacted with.

Attempt A Payment for a User Who is Not Logged In

payment_api_batch()

If the user you are making this payment for is not attached to this session, you can use this function instead.

from payments.payments_views.payments_api import payment_api_batch

if payment_api_batch(
    member=user,
    description="Party drinks",
    amount=3943.99,
    organisation=club,
    payment_type="Miscellaneous",
    book_internals=True,
):
    # Handle success
else:
    # Handle failure

Organisation Actions

This section has functions related to organisation payments.

Get an Organisation’s Balance

org_balance()

from payments.payments_views.core import org_balance

>>> get_balance(club)
400.0

Update an Organisation’s Account

update_organisation()

To update an organisations account, you can use update_organisation. Transactions should have either Stripe, a user or another organisation as the counterparty.

from payments.payments_views.core import update_organisation

update_organisation(
    organisation=item.organisation,
    other_organisation=system_org,
    amount=-item.balance,
    description=f"Settlement from {GLOBAL_ORG}. Fees {item.organisation.settlement_fee_percent}%. Net Bank Transfer: {GLOBAL_CURRENCY_SYMBOL}{item.settlement_amount}.",
    log_msg=f"Settlement from {GLOBAL_ORG} to {item.organisation}",
    source="payments",
    sub_source="settlements",
    payment_type="Settlement",
    bank_settlement_amount=item.settlement_amount,
)

GL Codes

Warning

This is currently a discussion section. Change this to factual documentation once the changes are made.

OrganisationTransactions have extra fields to track the purpose of the transaction. These are, rather incorrectly, internally labelled as GL Codes (General Ledger codes) as they are likely to ultimately end up being used in a similar way to GL codes by applications that take date feeds from Cobalt.

The structure of the fields is hierarchical. All fields are associated with a single organisation.

gl_transaction_type (choice field)

Top level. Effectively maps to the Cobalt application, currently just Congress or Session.

gl_category (text 50)

For a congress, this is the congress series name. For a session this is the session type. We only record the name as it stands when this is created, we don’t link to the underlying items.

gl_sub_category (text 50)

For a congress, this is the event. For a session it is the name of the session.

gl_series (integer)

For a congress, this is the year. For a session, this is a sequential number.

Examples

Examples of Codes

Transaction Type	Category	Sub Category	Series
Congress	NSBC Easter Congress	Open Pairs	2023
Congress	NSBC Easter Congress	Restricted Teams	2023
Congress	NSBC Easter Congress	Open Pairs	2024
Congress	NSBC Easter Congress	Restricted Teams	2024
Session	Duplicate	EL Tue 1:30pm Rookie	491
Session	Duplicate	EL Tue 1:30pm Rookie	492
Session	Duplicate	EL Tue 1:30pm Rookie	493
Session	Duplicate	RB Sat 10am Open	53
Session	Duplicate	RB Sat 10am Open	54

Potential Issues / Work

Congresses

Congresses are fairly straightforward. We can get all of the data we need just from the event and the congress. We don’t currently capture this information but it is a manageable change to add it.

We will record only the names of things as they are at the time the entry is made. This means there is no linkage back to the event, especially if it changes with time. For example, if one year it is “Honda Welcome Pairs” and the next year it is “Nissan Opening Pairs” then we won’t know they are the same event. That should be easy enough to handle in any downstream systems, and isn’t really a problem for Cobalt.

Sessions

We already store the session on the OrganisationTransaction. We can access the session data and save the GL info from this. The main problem is the sub-category which comes in as free format text. For the CompScore files we get the session description either from the file or from the file name. This seems reasonably reliable but needs manipulation to remove dates. It is not an ideal solution but we can also allow the director to change the sub-category on the settings page. The series can be generated.

Reporting

If we have the data available, as described above, we should be able to report in a number of ways. We can summarise at the category level (mostly for congresses) or the sub-category level (for congresses by event or sessions by session type such as Tuesday Open etc). We can also summarise at the series level for sessions which will show individual sessions.
