Utilities Application#

Note

This page has the documentation on how to use this application (externally provided APIs etc). If you are looking for information on how it works internally, you can find that in Supporting the Utilities Application.

Module Purpose#

Utilities is the place where we put things that don’t fit nicely anywhere else and aren’t big enough to warrant their own application.

There is much discussion in the community about whether you should have a utilities section, but Django has utilities so that is good enough for us.

External Usage#

Generic User Search#

This replaces the original generic user search which is still in the documentation below to allow supporting older code within Cobalt.

This is the preferred version for all new work.

The user search uses HTMX for a much cleaner coding experience.

To use it, add the following to your HTML template:

{% block footer %}
 {% include "accounts/search/user_search_include_htmx.html" with search_id={{ search_id}} include_me=True callback="MyFunc" %}

<script>
    function MyFunc(search_id, user_id, user_name){
    // do something
        console.log(search_id);
        console.log(user_id);
        console.log(user_name);
    }
</script>
{% endblock footer %}

To call it add a line to your HTML body:

<button type="button" class="btn btn-info" data-toggle="modal" data-target="#userSearchModal{{ search_id }}">Add</button>

Drop the include_me option if you do not want the logged in user to be included in the search results.

Note: You will often want to put this into an HTMX part of the system, in which case you don’t need the {% block footer %} part.

The user search dynamically adds functions using HTMX (https://htmx.org).

Originally it was intended to be able to work inline and to return a div with the name of the user, the hidden input and a button to search again. In practice only the callback version has been used so far. The code is still there to support the inline version (include search_include_inline_htmx.html if you want to use it), but it was never finished or tested.

Design#

If you have to support this, here is how it works.

It starts with user_search_include_htmx.html which has the modal and the HTMX calls to load the next parts. The bottom of the modal has a div that gets populated with the response from the server, either the user that is found or errors, or for the name searches a list of matches.

The modal is brought to the front by the button in the calling code.

The searches and templates are:

URL accounts:member_search_htmx

Other Components#
URL	View	Template
views.member_search_htmx	views.member_search_htmx	member_search_htmx.html
system_number_search_htmx	system_number_search_htmx	name_match_htmx.html
member_match_htmx	member_match_htmx	name_match_htmx.html

System_number_search returns the member_match template if it finds a match or sends an error itself.

With HTMX avoid adding Javascript dynamically over HTMX as it can be problematic. Here we use static Javascript functions which are loaded with the main page.

Generic User Search - Old. Do Not Use#

This is a client side utility that shows a pop up box for the user to search for another user. In order to implement this you need to do 4 things:

Import the body part of the HTML into your template:

{% include "utils/generic_user_search_body.html" with search_id=1 %}

Set up a button or similar HTML element to trigger the search:

<a class="cobalt_generic_member" data-toggle="modal" id="unique_id" data-target="#cobalt_general_member_search1">Add</a>

Change 1 to whatever search_id was set to.

Import the footer part of the HTML into your template:

{% block footer %}
<script>
{% include "utils/generic_user_search_footer.html" with search_id=1 %}

If you want to allow the user to include themselves in the search you can add include_me=True

Below the block footer, set up a function to handle a user selecting another member from the list:

function cobaltMemberSearchOk() {

// Do whatever
alert(member_id[1]);

</script>
{% endblock %}

There is also a callback for cancelling the search:

function cobaltMemberSearchCancel(search_id) {
// do something
}

Bringing it all together to make it easier to cut and paste:

{% include "utils/generic_user_search_body.html" with search_id=1 %}
<a class="cobalt_generic_member" data-toggle="modal" id="unique_id" data-target="#cobalt_general_member_search1">Add</a>
{% block footer %}
 <script>
 {% include "utils/generic_user_search_footer.html" with search_id=1 include_me=True%}
 function cobaltMemberSearchOk() {

 // Do whatever
 alert(member_id[1]);

 </script>
 {% endblock %}

Pagination Footer#

To use the same pagination footer (Next Page, Previous Page, etc at the bottom of a screen that is too big to show everything on one page.), you can use:

{% include 'utils/pagination_footer.html' %}

Your list must be called ‘things’ for this to work.

If you are paginating over a search list you will need to supply your search string as well. e.g.:

user = request.GET.get("author")
title = request.GET.get("title")
forum = request.GET.get("forum")
searchparams = "author=%s&title=%s&forum=%s&" % (user, title, forum)

return render(
    request,
    "forums/post_search.html",
    {"filter": post_filter, "things": response, "searchparams": searchparams},
)

HTMX Pagination Footer#

For HTMX you can use:

{% include 'utils/pagination_footer_htmx.html' %}

Your template should have tx_target, hx_post and hx_vars set.

Pagination Formatter#

Pagination in views is a common thing so we have a central utility for it:

from utils.utils import cobalt_paginator

my_list = ["some", "list", "to", "paginate"]
items_per_page = 20
things = cobalt_paginator(request, my_list, items_per_page)
return render(request, "mypage.html" {"things": things})

Unsaved Changes#

Lots of forms need to handle users navigating away from the page without saving changes. We have a JavaScript function to handle this:

<script src="{% static "assets/js/cobalt-unsaved.js" %}"></script>

You also need to identify which buttons are save buttons and should be ignored if pressed (i.e. don’t warn the user about navigating away with unsaved changes). Do this using the class cobalt-save:

<button type="submit" name="Save" class="cobalt-save btn btn-success">Save</button>

As this is loaded by default you need a way to tell it to ignore your page.

You can do this by adding any element with the id ignore_cobalt_save. e.g.:

<div id="ignore_cobalt_save"></div>

Template Filters#

You can use the following template filters:

{% load cobalt_tags %}

    {{ my_date_or_datetime|cobalt_nice_date }}

    e.g. Saturday 7th May 2022

    {{ my_time_or_datetime|cobalt_time }}

    e.g. 10am or 7:35pm

    {{ my_datetime|cobalt_nice_datetime }}

    e.g. Saturday 7th May 2022 11:32am

    {{ request.user|cobalt_user_link }}

    prints user with a link to their public profile. e.g.
        <a href='/accounts/public_profile/45'>Peter Parker(45654)</a>

Size Based Text#

If you want to have different text based upon the size of the screen (or anything else based on the size of the screen), you can use this:

<!-- Show on large screens, not small -->
<span class="d-none d-md-block d-lg-block">
  Administration
</span>
<!-- Show on small screens, not large -->
<span class="d-md-none d-lg-none d-xl-none d-xs-block d-sm-block">
  Admin
</span>

Cobalt Simple Form#

If you want a simple Bootstrap4 form and don’t need to customise the field set up, you can use this:

<form method="post" novalidate>
  {% csrf_token %}
  {% include 'utils/cobalt_simple_form.html' with form=my_form %}
  <button type="submit" class="btn btn-primary">Submit</button>
</form>

Batch Jobs#

Cobalt uses django-extensions django-extensions. to handle batch jobs. This allows us to have batch jobs defined within the applications to which they correspond.

Django-extensions creates a structure for us, e.g.:

cobalt\
      events\
            jobs\
              hourly\
                hourly_job_1.py
                hourly_job_2.py
              daily\
                my_daily_job.py
              weekly\
              monthly\
              yearly\

You can follow the examples to create new jobs.

Multi-Node Environments#

We generally only want the batch to run once so in a multi-node environment such as AWS we need to make sure the batch doesn’t run on all nodes. We can do this with a Cobalt utility:

from utils.views import CobaltBatch
from django_extensions.management.jobs import DailyJob

class Job(DailyJob):
    help = "Cache (db) cleanup Job"

    def execute(self):

      batch = CobaltBatch(name="My batch run", instance=5, schedule="Hourly" rerun=False)
# instance is optional and only needed if you run multiple times per day

      if batch.start():

# run your commands

        batch.finished(status="Success")
#        batch.finished(status="Failed")

As well as recording the start and end times of the batch job, CobaltBatch ensures that only one job per day per instance can be run. It does this by sleeping for a random time to avoid conflict and returning false for any subsequent job that tries to start. You can override this by specifying rerun=True (I don’t know how yet!).

Running Batch Jobs#

You need to run batch jobs from cron:

manage.py runjobs daily

For Elastic Beanstalk this can be set up with an install script.

AWS Utilities#

These are specific to the ABF implementation of Cobalt but can be modified for use on any other installation that uses AWS Elastic Beanstalk.

These commands also rely upon the configuration files and scripts that live in .ebextensions and .platform.

cobalt_aws_create_environment.py#

Creates a new Elastic Beanstalk environment including DNS entries. This requires a config file with the environment variables which for obvious security reasons is not kept within Github.

For usage run:

python cobalt_aws_create_environment.py -h

For example:

python cobalt_aws_create_environment.py cobalt-uat-pink /tmp/cobalt-uat.env --env_type uat -d uat3

EB Environment Name: cobalt-uat-pink
Input config file: /tmp/cobalt-uat.env
Environment type: UAT
DNS name: uat3.abftech.com.au

The most useful option is --env_type standalone which creates an environment with a local sqlite3 database. This won’t interfere with any other environment and can be used for specific testing. Note that creating a test or uat environment will replace the existing data in those databases with the default test data.

This script uses ssh to connect to the instance to complete set up. This is only intended for single node clusters and is not used for production systems which must set up their own environments. As ssh is used you will be prompted to confirm the first time connection. You can remove this check (not recommended unless you are okay with no server checking which can allow a man-in-the-middle attack) by adding this to your .ssh/config:

Host *
 StrictHostKeyChecking no
 UserKnownHostsFile=/dev/null

CGIT#

Cgit is a bunch of scripts to make working with Git and Elastic Beanstalk easier. They are not a required part of Cobalt, but they do live within the Cobalt source code inside utils (utils/cgit - you can add this to your path or copy the files to somewhere on your path, it is up to you).

Cgit only really runs on a Mac.

Installation#

Set up your path (or copy files) and you should be able to run:

cgit_help

This should get you started. If you don’t already have the EB CLI tool, the AWSCLI tool and git installed then you will have problems.

Additionally you need to install a diff viewer to use the reporting:

sudo npm install -g diff2html-cli

Usage#

cgit_help provides a list of all of the commands. They should be used in order. Cgit_help also shows the current versions installed in each environment.

Cgit adds descriptions to the Elastic Beanstalk releases so it can know exactly what is installed in each system. If you release without using cgit try to include this information anyway if you can:

eb deploy -m "<branch>@Sun_12/07/21_08:05"

cgit_util_compare#

$ cgit_util_compare production

Purpose: Compares the current branch with test, UAT or production.

Git Impact: None

Environment Impact: None

cgit_dev_start#

$ cgit_dev_start mine

Purpose: Creates a new development branch

Git Impact: Creates temporary development branch

Environment Impact: None

cgit_dev_save#

$ cgit_dev_save "My comment"

Purpose: Saves local changes to Github server

Git Impact: Updates Github branch with local changes

Environment Impact: None

cgit_dev_finish#

$ cgit_dev_finish

Purpose: Completes this work and updates develop branch and Test system

Git Impact: Updates develop branch. Deletes temporary branch.

Environment Impact: Updates Test with latest develop branch

cgit_uat_publish#

$ cgit_uat_publish

Purpose: Push changes to UAT system

Git Impact: Creates release branch with new number, release/x.y.z.

Environment Impact: Updates UAT with release/x.y.z

cgit_uat_fix_start#

$ cgit_uat_fix_start release/x.y.z myfix

Purpose: Creates a new branch to fix the code in UAT without pulling code from development.

Git Impact: Creates temporary fix branch release/x.y.z=myfix

Environment Impact: None

cgit_uat_fix_save#

Same as cgit_dev_save, saves current branch to Github server

cgit_uat_fix_finish#

$ cgit_uat_fix_finish

Purpose: Patches UAT

Git Impact: Updates release/x.y.z with fix. Deletes fix branch. Merges changes into develop.

Environment Impact: Updates UAT with patched release/x.y.z

cgit_prod_publish#

$ cgit_prod_publish

Purpose: Deploys release/x.y.z to production

Git Impact: None

Environment Impact: Updates Production with release/x.y.z

cgit_prod_hotfix_start#

$ cgit_prod_hotfix_start release/x.y.z myhotfix

Purpose: Starts working on a hotfix to go straight into production.

Git Impact: Creates branch release/x.y.z=hotfix=myhotfix

Environment Impact: None

cgit_prod_hotfix_save#

Same as cgit_dev_save, saves current branch to Github server

cgit_prod_hotfix_test#

$ cgit_prod_hotfix_test

Purpose: Releases hotfix branch to a test server (by default Test)

Git Impact: None

Environment Impact: Updates Test (or specified environment) with hotfix version. Note: Test may be ahead of Production in terms of migrations.

cgit_prod_hotfix_finish#

$ cgit_prod_hotfix_finish

Purpose: Patches release branch and deploys to Production.

Git Impact: Merges patch into release/x.y.z. Deletes patch branch.

Environment Impact: Updates production with hotfixed version release/z.y.z.

Mapping Branches to AWS Descriptions#

In test the branch will normally be develop, unless test has been used to trial a fix before releasing to another environment. The AWS description will be develop@<time>.

In UAT the description will be release/x.y.z@<time>. This will always match with the Github branch release/x.y.z which is patched whenever a fix is deployed.

In Production the description will be release/x.y.z@<time> or release/x.y.z–fixlabel@<time>. This will always match with the Github branch release/x.y.z which is patched whenever a fix is deployed. The extra part of the label is useful for knowing what the latest patch applied was. The branch release/x.y.z–fixlabel is kept for tracking purposes and will be identical to release/x.y.z when the hotfix is applied. Subsequently it can get out of step.

Utilities Application

Contents

Utilities Application#

Module Purpose#

External Usage#

Generic User Search#

Design#

Generic User Search - Old. Do Not Use#

Delete Modal#

Pagination Footer#

HTMX Pagination Footer#

Pagination Formatter#

Unsaved Changes#

Template Filters#

Size Based Text#

Cobalt Simple Form#

Batch Jobs#

Multi-Node Environments#

Running Batch Jobs#

AWS Utilities#

cobalt_aws_create_environment.py#

CGIT#

Installation#

Usage#

cgit_util_compare#

cgit_dev_start#

cgit_dev_save#

cgit_dev_finish#

cgit_uat_publish#

cgit_uat_fix_start#

cgit_uat_fix_save#

cgit_uat_fix_finish#

cgit_prod_publish#

cgit_prod_hotfix_start#

cgit_prod_hotfix_save#

cgit_prod_hotfix_test#

cgit_prod_hotfix_finish#

Mapping Branches to AWS Descriptions#
